Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16)

Send Inquiry

Request To Call Back

Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16)

Name: Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16)
Brand: OPTECH AIRCON ENGINEERS
Price: 109800 INR
Availability: InStock

Price 109800 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16) Specification

Condition
New

Temperature Control
Microprocessor-based Thermostat

Mounting
Ceiling Mounted

Type Of Compressor
Inverter Rotary

Power Consumption
2380 Watts

Filtration Grade
High (PM 2.5 Filter)

Sensible control
Yes (Precision Temperature Sensing)

Air Flow Capacity
1500 CFM (approx.)

Refrigerant
R-32

Power Mode
Inverter

Indoor Fan Input
65 W

Compressor
Rotary

Running Current
8.7 A

Dimension (L*W*H)
Indoor: 840 x 840 x 246 mm, Outdoor: 940 x 320 x 1240 mm

Power Supply
Single Phase, 220-240V, 50Hz

Cooling Capacity
9000 W

Place of Origin
India

Outdoor Fan Input
115 W

Type
Cassette AC

Cooling/Heating
Cooling Only

Capacity
2.5 Ton (9000 W)

Power Source
Electric

Voltage
220-240 V, 50 Hz, Single Phase

Color
White

Weight (kg)
Indoor: 29 kg, Outdoor: 70 kg (approx.)

Working Temperature
16C-52C

Fan Speed
3 Steps + Auto

Noise Level
37-45 dB (Indoor Unit)

Energy Efficiency Rating
3 Star

Remote Operated
Yes

Evaporator Fin Type
Hydrophilic Coated

Timer
Yes

Installation Kit
Included

Operating Modes
Auto, Cool, Dry, Fan

Eco Mode
Yes

Swing Function
4-way Air Swing

Auto Restart
Yes

Refrigerant Piping
Liquid: 9.5mm, Gas: 15.9mm

Maximum Piping Length
50 m

Maximum Height Difference
30 m

Self-diagnosis
Yes

Panel Model
BYCQ125EEF

Condenser Fin Type
Copper

Drain Pump
Built-in, Max. 850 mm Lift

Panel Weight
5.5 kg

Display
LED Hidden Display

Panel Dimensions
950 x 950 x 50 mm

Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16) Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Main Domestic Market
All India

About Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16)

The Daikin FCVFQ Series 2.5 TR 3 Star-Inverter Cassette Air Conditioner is a top-performing cooling system that delivers an Indoor Air Flow of 1218 CFM, with an Indoor Sound Pressure Level of 47 dBA High. With a Nominal Cooling Capacity of 2.5 TR, 9.0 kW and a Nominal Total Input Power of 2820 W (cooling), this air conditioner is an apt choice for small to mid-sized rooms. It comes with Outdoor Pipe Connection Flare (Type), 9.52mm (Liquid), and 15.88 mm (Gas). Its ISEER rating is 3.99 w/w, which makes it an energy-efficient and eco-friendly choice for home and office purposes. The unit is silver in color, and its dimensions are 840x840x298 mm. It is designed to be easy to install and use, making it a popular choice for residential and commercial use. With a warranty included, you can be sure that your investment is protected for years to come.

Indoor Air Flow1218 CFM

Indoor Sound Pressure Level47 dBA High

Max Piping Elevation15 m

Nominal Cooling Capacity2.5 TR,9.0 kW

Nominal Total Input Power2820 W (cooling)

Outdoor Pipe ConnectionFlare (Type),9.52mm (Liquid),15.88mm (Gas)

Output Unit Dimensions840x840x298 mm

Iseer3.99 w/w

FAQs of Daikin FCQF Series 2.5 TR 3 Star-Inverter Cassette Air Conditioner:

Q: What is the energy efficiency rating of the Daikin FCQF Series 2.5 TR 3 Star-Inverter Cassette Air Conditioner?

A: The energy efficiency rating of this air conditioner is Three stars.

Q: What is the ISEER rating of this air conditioner?

A: The ISEER rating of this Daikin air conditioner is 3.99 w/w, which means it is an energy-efficient choice for your cooling needs.

Q: What is the Indoor Air Flow rate of this air conditioner?

A: The Indoor Air Flow rate of this air conditioner is 1218 CFM.

Q: What is the warranty period provided with this air conditioner?

A: The Daikin FCVFQ Series 2.5 TR 3 Star-Inverter Cassette Air Conditioner comes with a warranty period, ensuring that your investment is protected for years to come.

Q: What is the maximum piping elevation for this air conditioner?

A: The maximum piping elevation for this air conditioner is 15 meters.

Advanced Cooling Performance

The Daikin FCVFQ90AV16 delivers a robust 2.5-ton cooling capacity, making it suitable for large rooms or open areas. Its inverter technology adjusts compressor speed for consistent temperatures and reduced energy consumption, even in demanding Indian climates. Four-way air swing and three-step fan speed ensure uniform comfort and minimal hotspots.

Comprehensive Features for User Convenience

Equipped with an integrated drain pump (850 mm lift), LED hidden display, and multiple operation modes (Auto, Cool, Dry, Fan, Timer), this cassette AC is designed for user-friendly operation. Auto restart, self-diagnosis, and high-grade filtration offer convenience and enhanced air quality, while eco mode promotes power saving.

Flexible Installation and Maintenance

With a sleek, ceiling-mounted design and a comprehensive installation kit included, the Daikin FCVFQ90AV16 is easy to set up in various settings. It supports extended refrigerant piping (up to 50 meters) and significant height difference (up to 30 meters), which makes it ideal for multi-storey buildings or unconventional layouts.

FAQ's of Daikin 2.5 Ton 3 Star-Inverter Cassette AC (FCVFQ90AV16):

Q: How does the Daikin 2.5 Ton Cassette AC ensure even cooling throughout the room?

A: This model features a 4-way air swing, three fan speeds (plus auto mode), and a high-capacity 1500 CFM airflow. Together, these functions distribute cool air evenly, minimizing temperature fluctuations in every corner of the space.

Q: What installation process is required for the Daikin FCVFQ90AV16 cassette AC?

A: The unit is ceiling-mounted and includes a dedicated installation kit. Installation should be performed by a qualified technician to ensure correct refrigerant piping, drainage (with built-in pump for up to 850 mm lift), and secure fitting of the 950 x 950 mm panel.

Q: When should the self-diagnosis feature be used?

A: The self-diagnosis function automatically detects operational issues or system errors, which are indicated via the LED hidden display. This feature should be used whenever there is inconsistent cooling or unusual operation, as it helps to pinpoint problems for faster service.

Q: Where can the Daikin 2.5 Ton Inverter Cassette AC be installed?

A: Perfect for commercial offices, large living rooms, conference rooms, or retail spaces, this ceiling-mounted unit can be installed in any area with appropriate ceiling space and electrical supply. Its extended piping length (up to 50 m) and significant height allowance (30 m) enable flexible placement even in complex buildings.

Q: What are the benefits of using an inverter rotary compressor in this air conditioner?

A: The inverter rotary compressor provides more precise temperature control, saves energy by adjusting speed based on cooling demand, generates less noise (37-45 dB), and generally extends the lifespan of the AC compared to traditional models.

Q: How does the PM 2.5 filter enhance air quality?

A: The high-grade PM 2.5 filter captures fine particulate matter, improving indoor air quality by reducing dust, allergens, and pollutants, which is especially beneficial for those with respiratory concerns or allergies.

Q: What energy-saving modes are available, and how do they work?

A: Eco mode lowers overall power consumption, while the timer function allows you to schedule operation times, both of which reduce energy use. The inverter technology further boosts efficiency by matching cooling output to actual demand.
